A modular guide to interfacial redox processes and their practical implications

Electrochemical reactions occur at the interface between an electrode and an electrolyte, where electrons cross from a conductive solid into ionic species in solution. These processes form the basis of metal electroplating, gas evolution, and corrosion, influencing everything from industrial production to materials stability and energy conversion.

In this lecture, we examine how electrode reactions proceed at a molecular level, how potential and current govern them, and how these mechanisms underpin both useful technologies and undesirable degradation. We’ll explore Faraday’s laws, electrode kinetics, gas evolution reactions, and the electrochemical origins of corrosion.

By the end, you’ll understand how redox processes manifest at electrodes when they are harnessed for manufacturing, and when they must be controlled or prevented.

1. Introduction: Electrode Reactions as Interfacial Events

An electrode reaction is a redox process that occurs at the boundary between a solid conductor (the electrode) and an ionic medium (the electrolyte).

At the cathode, reduction occurs:

At the anode, oxidation occurs:

The electrode acts as a site for charge transfer, converting between ionic and electronic currents.

Such interfacial processes are essential for:

• Electrolysis
• Battery discharge and recharge
• Electroplating
• Fuel cell operation
• Corrosion

Reference: Royal Society of Chemistry – Electrochemical Interfaces

2. Electron Transfer and the Electrode Surface

At the molecular level, electrode reactions depend on:

• Electron tunnelling through the double layer
• Adsorption of reacting ions or molecules
• Charge-transfer kinetics governed by activation energy

The rate of an electrode reaction depends on how easily electrons cross this electrode–solution interface, described by the Butler–Volmer equation:

where:

• i = current density
• i₀ = exchange current density
• η = overpotential
• α = transfer coefficient

This equation captures how the reaction rate changes with applied potential, defining the kinetics of electron transfer.

3. Metal Deposition (Electroplating)

3.1. Principle

Metal deposition involves the reduction of metal ions from solution onto a cathode surface:

This process is used for:

• Electroplating decorative or protective coatings (e.g. nickel, chrome, gold)
• Electrowinning extraction of metals from ores (e.g. copper, aluminium)
• Manufacturing of electrical contacts, printed circuits, and batteries

3.2. Faraday’s Laws of Electrolysis

1. First Law: The mass of substance deposited (or liberated) is proportional to the charge passed.

where Q = I x t is the charge.

2. Second Law: For equal charges, the masses deposited are proportional to their equivalent weights.

Example:
Electrolysis of copper sulphate:

If 2 A current runs for 30 minutes:

This relationship is foundational in electrochemical engineering and process design.

Reference: LibreTexts – Faraday’s Laws

4. Mechanism of Metal Deposition

Metal deposition typically proceeds via three stages:

1. Mass Transport – Metal ions diffuse to the electrode surface.
2. Electron Transfer – Reduction of ions to metal atoms.
3. Crystal Growth – Atoms nucleate and form a coherent layer.

Surface structure, temperature, and overpotential control grain size, adhesion, and uniformity of deposited metal.

At higher overpotentials, hydrogen evolution may compete:

This parasitic reaction reduces efficiency and affects coating quality.

Reference: ScienceDirect – Electrodeposition Principles

5. Gas Evolution Reactions (GERs)

When aqueous solutions are electrolysed, gas evolution often accompanies redox processes at electrodes.

5.1. Hydrogen Evolution Reaction (HER)

At the cathode:

or in alkaline media:

HER is crucial in:

• Water electrolysis
• Fuel cell cathodes
• Hydrogen production technologies

Catalysts such as platinum, nickel, and molybdenum disulfide (MoS₂) lower the overpotential and enhance efficiency.

5.2. Oxygen Evolution Reaction (OER)

At the anode:

OER is a four-electron process and thus kinetically sluggish. Catalysts (e.g. IrO₂, RuO₂, NiFe oxides) are required to reduce activation barriers.

Reference: Nature Energy – Hydrogen and Oxygen Evolution Mechanisms

6. Overpotential and Efficiency

The actual potential required to drive an electrode reaction often exceeds the thermodynamic value due to overpotential (η).

Types include:

• Activation overpotential – due to kinetic barriers in electron transfer.
• Concentration overpotential – due to mass transport limitations.
• Ohmic overpotential – due to resistance in electrolyte or electrode materials.

Minimising these effects is essential for efficient electrolytic and energy systems.

Example:
In water electrolysis:

The difference is attributed to total system overpotential.

7. Corrosion: The Unwanted Electrochemical Reaction

7.1. Definition

Corrosion is the spontaneous oxidation of a metal by its environment, converting it to more stable compounds such as oxides, hydroxides, or carbonates.

7.2. Fundamental Redox Nature

At the anodic sites:

At the cathodic sites (in acidic medium):

or in neutral oxygenated water:

The result is rust formation:

Reference: Corrosionpedia – Fundamentals of Corrosion

8. Types of Corrosion

1. Uniform corrosion – general attack over the entire surface.
2. Galvanic corrosion – two dissimilar metals are electrically connected in an electrolyte.
3. Pitting corrosion – localised attack forming deep pits.
4. Crevice corrosion – in stagnant microenvironments.
5. Intergranular corrosion – along grain boundaries in alloys.

Galvanic corrosion follows the electrochemical series: the more reactive metal acts as anode and corrodes first.

Example:

Zinc (anodic) protects copper (cathodic).

9. Protection and Prevention of Corrosion

Methods include:

• Protective coatings (paint, plating, anodising)
• Sacrificial anodes (zinc, magnesium on steel structures)
• Cathodic protection (applying an external current to make the metal cathodic)
• Corrosion inhibitors (chemicals forming protective films)
• Environmental control (reducing oxygen, humidity, or chloride ions)

Example:
In pipelines, an external DC source supplies electrons, keeping steel as the cathode:

Reference: NACE International – Cathodic Protection Overview

10. Industrial Applications of Electrode Reactions

Application	Key Reaction	Purpose
Electroplating	Mⁿ⁺ + n e⁻ → M(s)	Decorative/protective coatings
Electrowinning	Reduction of metal ions from ores	Metal extraction
Chlor–alkali process	2 NaCl + 2 H₂O → 2 NaOH + Cl₂ + H₂	Industrial chemicals
Water electrolysis	2 H₂O → 2 H₂ + O₂	Hydrogen fuel
Corrosion cells	Fe → Fe²⁺ + 2 e⁻	Unwanted degradation

These examples show how electrode reactions underpin both production and protection in modern industry.

11. Gas Bubble Dynamics and Electrode Performance

Gas evolution affects electrode efficiency:

• Gas bubbles reduce the active area.
• They alter local conductivity and pH.
• Bubble detachment depends on surface roughness and wettability.

Advanced designs use hydrophobic coatings, microstructured electrodes, or ultrasonic agitation to promote efficient gas release.

Reference: Electrochimica Acta – Gas Bubble Effects in Electrolysis

12. Energy Devices and Electrode Reactions

Electrode reactions drive all electrochemical energy devices:

• Batteries: reversible electrode redox reactions store energy.
• Fuel cells: a continuous supply of fuel and oxidant maintains the reaction.
• Electrolysers: reverse of fuel cells, storing energy as chemical fuel.

Example – Hydrogen fuel cell:

Understanding electrode reactions enables optimisation of catalysts, current densities, and cell design.

13. Electrode Materials and Surface Engineering

Electrode performance depends critically on:

• Conductivity
• Chemical stability
• Surface morphology
• Catalytic activity

Common materials:

• Platinum: inert, excellent catalytic properties.
• Graphite: inexpensive, conductive.
• Nickel: used in alkaline systems.
• Titanium-coated oxides (DSA): dimensionally stable anodes for chlorine production.

Emerging materials include graphene, MXenes, and nanostructured catalysts with enhanced redox activity and durability.

Reference: ACS Applied Materials – Advanced Electrode Materials

14. The Thermodynamic–Kinetic Balance

Electrode reactions obey the same thermodynamic rules as any redox system:

but the kinetics determine whether they are practically useful.

• A large positive ECell implies spontaneity.
• A large overpotential implies slow kinetics.

Engineering seeks to align both achieving reactions that are both energetically favourable and fast.

15. Summary and Learning Outcomes

By the end of this lecture, you should be able to:

Explain how electrode reactions occur at interfaces and distinguish between anodic and cathodic processes.
Apply Faraday’s laws to quantify metal deposition.
Describe hydrogen and oxygen evolution reactions and their catalysts.
Explain corrosion mechanisms and protection methods.
Understand overpotential, efficiency, and kinetic control in electrode processes.
Identify how electrode reactions underpin industrial, energy, and environmental technologies.

Further Reading and References

• RSC Education – Electrochemistry Resources: Electrochemical Interfaces
• ScienceDirect – Electrodeposition Principles: Electrodeposition
• NACE International – Corrosion Prevention: Cathodic Protection
